● 35A 277VAC以上切換容量，有40A/50A 277VAC可選 35A 277VAC switching capacity or higher, with options of 40A/50A 277VAC ● 觸點與線圈間介質耐壓5KV Dielectric strength between the contacts and the coil: 5KV ● 觸點間隙1.8mm可選，符合歐洲VDE0126光伏標準 Contact gap options of 1.8mmmm, compliant with European photovoltaic standard VDE0126 ● 低功耗，低溫升，低保持；40A/50A載流溫升低與50K Low power consumption, low temperature rise, low holding power; low current temperature rise of 40A/50Aand 50K ● 具有一組常開 Equipped with a set of normally open contacts ● 線圈功耗 0.9W/1.4W/1.6W/3.8W Coil power consumption: 0.9W/1.4W/1.6W/3.8W |
Z10F | ||||||||
基本型號 Type Z10: PCB端子 | ||||||||
線圈額定電壓 Coil Voltage 05，09，12，24，48 | ||||||||
線圈功耗 Nominal Power Blank=0.9W,L=1.4W,D=1.6W,H=3.8W | ||||||||
觸點結構 Contact of Arrangement 1A=Form1A | ||||||||
封裝形式 Category of Protection Blank=非密封型 Flux proof, S=密封型 Wash Tight | ||||||||
負載類型 Rating Blank=35A 250VAC, T40=40A 250VAC, T50=50A 250VAC, | ||||||||
觸點間隙 Contact Gap Blank=標準間隙Standard, G=大間隙Big Gap (1.8mm) | ||||||||
特殊標記 Suffix Blank=Standard, (XXX)=客戶特殊需求 Customer Special Requirement | ||||||||
